Initial use: books, DVD

A)     Sorter mechanically

• Type of Sorter                 EuroSort ESF 43 DS
• Type tray is Dual split, dimension 2 x 400 x 300mm
• 151 Destinations, included
•  special stations (no read, overflow, reject)
• including 4 belt exits with length 2000mm
• compartment with soft landing & pack-out table
• Overfill: 2 overfill sections per sorter side (2x2 sets)
• 1 Lamp per destination, colour blue
• Capacity 2 x 7.200 = 14.400 trays per hour
• Pitch between the destinations is ca. 500 mm
• 2 infeed position direct at the sorter with a PC / fixed scanner on a platform
• 2 sorter motors

·        Sorterlength ca. 45 m

B)     Automatic infeed line

• Automatic infeed belt with 180deg. curve
• 2x4 infeed positions at the automatic induction belt.
• 1x camera scanner Vitronic
• 2x2 Logopak price labellers

·        Labelverify scanner

• 2x1 in line volume measurement device

C)     Controls hardware: sorter

• PLC (VIPA 317) hardware only, no PLC SW
• 8 RF scanners
• All necessary safety switches
• WMS/Server: not included, no Hardware PC’s
• Controls cabinets

D)     Conveyors under sorter

• 2 accuveyor for supply of empty boxes (400 mm)
• 2 ambaveyor for discharge filled boxes (600 mm)

E)     Set of spare parts
